基本特性 LTE FDD: Band 1/3/5/8
LTE TDD: Band 34/38/39/40/41
GSM: 900/1800MHz
LCC 16 × 18 × 2.3mm
Operating Temperature: -40℃~+85℃
Storage Temperature: -40℃~+85℃
Operating Voltage: 3.3V~4.3V typical 3.8V
AT Command Set: 3GPP TS 27.007 and 27.005,
and proprietary FIBOCOM AT commands
TX Power GSM900: 32.5 dBm±1dB DCS1800:
29.5dBm±1dB LTE FDD: 23.0dBm±1dB LTE TDD:
23.0dBm±1dB
接口
SIM Card: 1.8V/3.0V
USB 2.0
UART
I2C
PCM/I2S**
ADC
SDIO**
SPI**
GPIO
Antenna: Main
认证
CCC*/SRRC*/NAL*/CE*/RoHS*
传输速率
LTE FDD: 10Mbps DL/5Mbps UL
LTE TDD: 10Mbps DL/5Mbps UL
GPRS: 107Kbps DL/85.6Kbps UL
功能
MUX: Basic Mode
SMS: MO/MT Text and PDU modes
HTTP(S)/FTP(S)/TCP(S)/UDP/IPV4/IPV6/MQTT
ECM/RNDIS/PPP
DFOTA/FOAT
