| 基本特性 |
Memory(Default): 1GB LPDDR3 RAM; 8GB eMMC Flash
Dimension(mm): 40.50 x 40.50 x 2.85
Package: 146 LCC pin + 64 LGA pin
OS: Android Lollipop/Nougat
Voltage: DC 3.3-4.5V
Operating Temp.: -30°C ~ +70°C
Weigh: about 9.2g
|
|
|
处理器 |
Chipset: MSM8909
Core：4 x ARM Cortex-A7
CPU Frequency：1.1 GHz
GPU：Adreno 304 @ 400MHz
|
|
|
传输速率 |
LTE FDD: Max 150Mbps (DL)/Max 50Mbps (UL)
LTE TDD: Max 130Mbps (DL)/Max 30Mbps (UL)
UMTS/HSPA/HSPA+: 3GPP R8 HSPA+ Max 42Mbps(DL)/3GPP R6 HSUPA Max 5.76Mbps(UL)
TD-SCDMA: 3GPP R8 Max 4.2Mbps(DL)/Max 2.2Mbps (UL)
CDMA2000 1X/EVDO: Max 3.1Mbps(DL)/Max 1.8Mbps(UL)
EDGE: Max 296kbps(DL)/Max 236.8kbps(UL)
GPRS: Max 107kbps(DL)/Max 85.6kbps(UL)
Wi-Fi: up to 150Mbps (SC806-CN: up to 72.2Mbps)
|
|
| 音视频特性 |
Video Encode: 720p@30 H.264BP/MP–720P,30fps MPEG-4SP/H.263P0–WVGA,30fps VP8–WVGA,30fps
Video Decode: 1080P@30 H.264BP/MP/HP–RES, 30fps MPEG-4SP/ASP–RES, 30fps DivX4x/5x/6x–RES, 30fps H.263P0–WVGA, 30fps VP8–RES, 30fps
Speaker: 1 x Mono,differential 800mW CLASS-D
Receiver: 1 x Mono, AB
Mic: 3 x analog microphones
Handset: 1 x Stereo, single-ended output
|
|
| 接口 |
UART/SPI: 2 x UART Up to 4Mbps, 1 x SPI
I2C: 2 x I2C Up to 3.4Mbps
USB: 1 x USB2.0 up to 480Mbps ,Support OTG(Require 5V power supply)
SDIO: 1 x SD3.0
CAM: 1 x MIPI CSI-2lanes (up to 8Mp) 1 x MIPI CSI-1lanes (up to 2Mp)
GPIO: typical 24 x GPIO
Display: 1 x MIPI DSI- 4lanes 720P
Keys: Power on/off ,Volume up,Volume down,Reset
USIM: 2 x SIM card, support dual-card dual-standby(Default Single)
|
| 认证 |
RoHS/CE/CCC/FCC/GCF/RCM*/PTCRB*/AT&T*/Verizon* |
