该模块支持多种网络协议（PAP、CHAP、PPP）和多种功能（FOTA, TTS，Remote wakeup等），并能提供USB，UART，SDIO，IIC，SPI等硬件接口。
该模块支持宽温工作，可广泛应用于移动宽带，公网对讲，无线支付，车载，安防监控、智能物流、智慧工业等多种物联网应用场景。
基本属性
pLCC Form Factor (80 pins)
pPin-to-Pin with ME3630
pDimensions: 30mm × 30mm× 2.3mm
pFrequency Band :
–LTE FDD/LTE TDD
环境适应性
pOperation temperature: -30°C to +75°C
–Extreme Operating temperature: -40°C to +85°C
pStorage temperature: -40°C to +85°C
pHumidity: 5%~ 95%
GM510 系列频段信息
电气及灵敏度
pTransmit Power:
–LTE: 23 ±2.7dBm (Power Class 3)
pReceiving sensitivity:
–Rx Diversity *
pPower Supply :
–3.4V -- 4.2V(3.8V is recommended)
PID
Band
Rx Diversity
C1A
LTE FDD: B1, B3, B5, B8
LTE TDD: B34,B38,B39, B40, B41
Yes
C1B
LTE FDD: B1, B3, B5, B8
No
C1C
LTE FDD: B1, B3, B5
No
C1D
LTE FDD: B1, B3, B5, B8
LTE TDD: B34,B38,B39, B40, B41
No
模块接口
pUSB 2.0 High speed (480 Mbps)
pUART1(4-wires)
pUART2 for debug (2-wires)
pSIM interface (1.8/3.0V)
pSPI
pI2C
pAntenna (RF PAD for Primary, Diversity)
pLED indication
pReset & Power-on
pWAKE-IN & WAKE-OUT
应用功能
pSupport embedded TCP & UDP protocols
pSupport protocols PAP and CHAP used for PPP connection
pUSB Selective Suspend & Remote wakeup
pRAS /ECM/RNDIS
pControl Via AT Commands according to 3GPP TS27.005, 27.007 and GOSUNCN extended AT commands
数据特性
pLTE FDD
–Uplink 50Mbps / Downlink 150 Mbps
pLTE TDD
–Uplink30Mbps / Downlink 112Mbps
驱动&工具
pDrivers
–Windows XP, Vista, 7 , 8, 10
–Linux
pDiag-log Tool
pFirmware Update Tool
